TWN 1839/1
Clevis Sling Hooks with Swivel Adapter

The grade 10 clevis sling hooks with ball bearing swivel adapter TWN 1839 are used for the twist-free alignment of the individual suspension strands.
The swivel adapter is mounted on the clevis design system of the clevis sling hook.
The large eyelet of the swivel adapter enables, e.g. a connection to a chain or rope strand as well as textile slings.
The slip hook has forged measuring points as limit values that enable the max. hook mouth width to be checked.
The manufacturing and testing requirements of the clevis sling hook with swivel adapter correspond to DIN EN 1677-2 and DIN EN 1677-1 under consideration of the grade 100 load capacities.
